1C31224G01
Product Description: The 1C31224G01 is an analog input module designed for Emerson’s Ovation™ distributed control system (DCS). It provides eight independent channels for receiving analog signals, specifically 4-20mA current signals from field instruments. The module features a 14-bit resolution for accurate conversion of these analog inputs into digital values for processing by the Ovation™ controller. It is a crucial component for interfacing with various sensors and transmitters that output a 4-20mA signal, enabling the Ovation™ system to monitor and control industrial processes.
Product Parameters (Typical):
- Number of Input Channels: 8
- Input Signal Type: 4-20 mA current loop
- Resolution: 14 bits
- Input Impedance: Typically around 250 ohms (to develop a voltage for the A/D converter)
- Isolation: Galvanic isolation between channels and from the system backplane (confirm with specific datasheet)
- Accuracy: Refer to the specific product datasheet for accuracy specifications.
- Update Rate: Refer to the specific product datasheet for the sampling and update rates.
- Power Consumption: Refer to the specific product datasheet for power requirements.
Specifications (Typical):
- Manufacturer: Emerson Automation Solutions (originally Westinghouse, then part of Invensys, now Emerson)
- Part Number: 1C31224G01
- System Compatibility: Emerson Ovation™ DCS
