A-B 1756-IF16

Product Name:

• • Allen-Bradley 1756-IF16 Analog Input Module
• Product Description:
  • The Allen-Bradley 1756-IF16 is an analog input module.
  • It is part of the Allen-Bradley ControlLogix series of programmable logic controllers (PLCs).
  • It is designed to receive analog input signals, such as voltage and current, from field devices.
  • It is used to bring in analog signals from external devices, into the PLC.
• Product Parameters and Specifications:
  • Manufacturer: Rockwell Automation/Allen-Bradley
  • Series: ControlLogix
  •
  • Part Number/Catalog No.: 1756-IF16
  • Analog signals: ±10V, 0-10V, 0-5V and 0-20 mA
  • Number of Inputs: 16 single ended, 8 differential or 4 differential (high speed)
  • Resolution: various depending on the voltage or current range.
  • Backplane Current (5Volts): 150 milliamps
  • Backplane Current (24Volts): 65 milliamps
