ABB 3BHB012961R0001

• Module Number: 3BHB012961R0001
• Manufacturer: ABB
• Function: Integrated Gate-Commutated Thyristor (IGCT) module.

Product Description:

• The ABB 3BHB012961R0001 is an Integrated Gate-Commutated Thyristor (IGCT) module.
• This type of module is used in high-power industrial applications, particularly in areas requiring high-power switching.
• It is frequently found within industrial drives and power distribution systems.
• It is also shown in some vendor information that it can be a hybrid IGCT/IGBT module. meaning it combines the advantages of insulated-gate bipolar transistors (IGBTs) and integrated gate-commutated thyristors (IGCTs).
•

Key Features and Specifications:

Based on the search results, here are some key aspects:

• IGCT module.
• Hybrid IGCT/IGBT design in some cases.
• High-power switching capabilities.
• Used in industrial drives and power distribution.
• High switching speeds.
• low conduction losses.
• High current handling capability.
• Voltage rating: 2600 V.
• Current rating: 4500 A.
• Switching frequency: 10 kHz.
• Cooling method: Water cooling.
