ABB 5SHX1445H0001

Based on the available information, here’s the English information for the ABB 5SHX1445H0001 module:

Product Name: IGCT Module 5SHX1445H0001

Product Description: The 5SHX1445H0001 is an IGCT (Integrated Gate-Commutated Thyristor) module manufactured by ABB. IGCTs are high-power semiconductor switching devices used in applications requiring efficient control of large voltages and currents. This specific module is designed for demanding industrial and power transmission applications.

Product Parameters (Likely):

While a specific datasheet for the 5SHX1445H0001 wasn’t immediately available, based on the general characteristics of IGCT modules and similar ABB part numbers, typical parameters would include:

• Voltage Rating: Likely in the medium to high kilovolt range (e.g., several kV).
• Current Rating: Likely in the kiloampere range (e.g., several kA).
• Turn-off Time: Very fast, typically in the microsecond range.
•
• Gate Drive: Requires a dedicated gate drive unit for proper operation.
• Cooling: Typically requires forced air or liquid cooling due to significant power dissipation.

Specifications (Likely):

• ABB Part Number: 5SHX1445H0001
• Device Type: IGCT (Integrated Gate-Commutated Thyristor)
• Manufacturer: ABB
• Technology: Integrated Gate Commutated Thyristor (IGCT)
• Applications (Typical for IGCTs):
  • Medium voltage drives
  • Marine drives
