ABB D0820

Based on the available information, the ABB D0820 module is a Digital Output Module, specifically identified with the part number 3BSE008514R1.

Product Name: ABB DO820 Digital Output Module

Product Description:

The ABB DO820 is a digital output module featuring 8 channels with relay outputs. It is part of the ABB S800 I/O system and is designed for use in ABB PLC (Programmable Logic Controller) systems, likely within the ABB Ability™ System 800xA®. This module provides a reliable interface to control external digital devices such as actuators, contactors, and indicators by switching DC or AC voltages within the specified range.

Key Characteristics:

• 8 Digital Output Channels: Provides eight independent output channels.
• Relay Outputs: Utilizes relay contacts for switching the output circuits.
• Wide Voltage Range: Supports output voltages from 24 to 250 V AC/DC.
• Part of S800 I/O: Designed for integration with the ABB S800 I/O system.
• ABB PLC Compatibility: Used with ABB Programmable Logic Controllers.

Product Parameters:

• Manufacturer: ABB
• Part Number: 3BSE008514R1 (also referenced as D0820)
• Product Type: Digital Output Module
• Number of Channels: 8
•
• Output Type: Relay
• Output Voltage Range: 24 to 250 V AC/DC
• Dimensions:
  • Width: 45 mm (1.77 inches)
  • Depth: 102 mm (4.01 inches), 111 mm (4.37 inches) including connector
  • Height: 119 mm (4.7 inches)
• Weight: 0.23 kg (0.5 lbs)

Specifications:

• Manufacturer: ABB
• Model: DO820
• Series: S800 I/O
• Mounting: DIN Rail
