ABB DI840

• The ABB DI840 is a 16-channel 24 V d.c. digital input module.
• It is part of ABB’s S800 I/O system, designed for use in industrial automation and control applications.
• It is designed for single or redundant applications.
• It is used to interface with digital input signals from field devices.
• It is a component of the ABB Ability™ System 800xA®.

Key Features and Specifications (General):

• Type: Digital Input Module
• Channels: 16
• Voltage: 24 V d.c.
• Applications:
  • Industrial automation
  • Process control
  •
  • Safety systems
• Key features:
  • Redundant capabilities.
  • Diagnostic functions.
  • LED indicators for I/O status.
• General Information:
  • Dimensions: Width 45 mm (1.77”), Depth 102 mm (4.01”), 111 mm (4.37”) including connector Height 119 mm (4.7”) Weight 0.15 kg (0.33 lbs.)
  • Input voltage range, “0” | -30..+5 V
  • Input voltage range, “1” | 11..30 V
  • Input impedance | 3.3 kΩ
  • Isolation | Groupwise isolated from ground
  • Filter times (digital, selectable) | 0 to 127 ms
