ABB LD800HSE
Product Description: The ABB LD 800HSE is a linking device designed to connect FOUNDATION Fieldbus (FF) High Speed Ethernet (HSE) subnets with FF-H1 links. It acts as a gateway, enabling access to field devices connected to the FF-H1 network from supervisory and control systems, as well as management consoles, via the HSE protocol. The LD 800HSE supports device redundancy, enhancing the reliability of the fieldbus communication. It provides the necessary power and communication interface for the H1 segments.
Product Parameters:
- Number of H1 Links: 4
- HSE Communication: Ethernet
- Redundancy: Supports device redundancy
- Power Supply to H1 Segments: Provides power for the con
- nected FF-H1 devices.
- Communication Protocol: FOUNDATION Fieldbus HSE and H1
Specifications:
- Mounting: Typically designed for DIN rail mounting.
- Connectors: Includes connectors for HSE (Ethernet) and multiple H1 fieldbus segments. Specific connector types and numbers will be detailed in the product datasheet.
- Operating Temperature: Consult the specific product datasheet for the operating temperature range.
- Power Consumption: Consult the specific product datasheet for power consumption details.
- Dimensions: Consult the specific product datasheet for physical dimensions.
