ABB LD800HSE 3BDH000320R02

• ABB LD800HSE Module
• ABB LD800HSE FF Linking Device

Product Description:

• The ABB LD800HSE is a FOUNDATION Fieldbus (FF) Linking Device.
• It serves as a gateway between FF’s High Speed Ethernet (HSE) and H1 field devices.
• It enables access to field devices connected to FOUNDATION Fieldbus from supervisory and control systems, as well as management consoles.
• It is used to interface between High Speed Ethernet (HSE) and H1 devices.

Product Parameters and Specifications:

Here are some key parameters based on the search results:

• Interface:
  • HSE Interface: 1 channel 10 Mbit/s or 100 Mbit/s (autosensing).
  • H1 fieldbus interface: 4 channels 31.25 kbit/s.
• Mechanical design:
  • Dimensions: 47 x 131 x 111 mm (mounted on DIN rail 35 mm).
  • Weight: approximately 0.4 kg.
  • Degree of protection: IP 20.
• Environmental conditions:
  • Operating temperature: 0°C to +55°C.
  • Storage temperature: -20°C to +70°C.
