Bentley 3500/33

Product Description:

The module is a full height module that provides 16 relay outputs.
It can be placed in any slot on the right side of the Transient Data Interface (TDI) module.
Each output of the 3500/33 16-channel relay module can be programmed independently to perform voting logic.
Each relay in the module contains alarm driver logic.
Alert-driven logic is programmed using AND and OR logic, and the following can be used:

Alert input (alert and danger status).
Abnormal operation.
Individual measurement variables from any monitor channel or combination of monitor channels in the rack.
The alarm driver can be programmed using 3500 rack configuration software.
The module is part of the Bently Nevada 3500 mechanical condition monitoring system.
Product parameters and specifications:

Input:
Power consumption: Typical value is 5.8 watts.
Output:
Front panel LED:
OK LED: Lights up when the 3500/33 16-channel relay module is operating normally.
TX/RX LED: Transmission and reception blink when the 3500/33 16-channel relay module is communicating with other modules in the 3500 rack.
CH Alarm LED: Lights up when the relay channel is in an alert state
