GE IS200WETBH1B
GE IS200WETBH1B Printed Circuit Board
Product Description
The GE IS200WETBH1B is a printed circuit board that is part of the Mark VI system in the Speedtronic series2. It is designed for use in gas/steam turbine control systems developed by General Electric from the 1960s to the 1990s2. This module is equipped with both general – purpose I/Os and application – specific I/Os, which are responsible for controlling and monitoring aspects such as flame detection, vibration, shaft voltage build – up, and proper syn
chronization2.
The IS200WETBH1B is a component – dense board2. There is an exposed copper strip on its edge, which is factory – drilled at regular intervals2. Most of the board’s 65 + plugs and connectors are distributed along the edges, including plugs with 2 to 20 positions and female jacks ranging from 4 to 12 positions2. There are also three vertical male connectors inside the board: P1 is a 10 – pin connector, P2 is a 6 – pin header, and P3 is a 4 – pin header2. In addition, the board is equipped with various components such as a single transformer, over thirty relays of two types, fuses, jumpers, heat sinks, voltage regulators, coil inductors, test points, a single switch, over fifty integrated circuits, varistors, high – voltage electrolytic capacitors, and metal – film resistors6.
Product Parameters
- Operating Voltage: It usually operates within a certain voltage range to meet the power supply requirements of the Mark VI system. However, the specific voltage value is not publicly available without detailed technical documentation.
- Communication Protocol: Supports relevant communication protocols of the Mark VI system to ensure effective data interaction and communication with other modules and components in the system. The specific communication protocol details depend on the overall design and requirements of the Mark VI system.
- Input/Output Signal Type: Can handle various types of input and output signals, including digital signals
