GE IS215UCVEM09B
This module features jumper pins that create manual switches to direct the energy flow1. Its panel is equipped with multiple Ethernet ports and other types of connection terminals, each labeled with its purpose, and some terminals have additional spaces for cable fixation1. The module can use its resistors to dissipate the excess energy accumulated on the circuit board1. It is equipped with tower – type and box – type condensers, which are used to generate electric – energy fields that store electric energy for the circuit board’s future use1. The IS215UCVEM09B uses diodes and traces on the circuit board surface to guide the energy flow1. In addition, it has several terminals for connecting the circuit board in place and enabling communication between circuit boards1. It also comes with a battery and an SD card, and there is a small circuit board fixed to the main board from the panel.
Product Parameters
- Operating Voltage: Usually 10V1.
- Communication Interfaces: Multiple Ethernet ports for high – speed data transmission with other Ethernet – compliant devices.
- Diagnostic Functions5:
- Software Filter Integration Time: It specifies the time in milliseconds for the software filter to reach 63.2% of the input value. A value of 0 indicates the software filter is disabled, and a value of 100 means data will achieve 63.2% of its value in 100ms. The default is disabled.
- Diagnostic Reporting Enable: If enabled, it allows reference memory reporting of alarms into the diagnostic reference area, and fault logging of alarms into the I/O fault table. The interrupt enable option can trigger the I/O interrupt when alarm conditions occur.
Product Specifications
- Physical Dimensions1: Approximately 16cm×11cm×6cm.
- Weight1: About 0.86kg.
- Operating Temperature: Suitable for industrial – grade operating environments, usually within a range of – 40°C to + 85°C.
