GE PCI-5565PIORC-111000
Product Name: cPCI-5565PIORC Reflective Memory Module
Product Description:
The GE cPCI-5565PIORC (CompactPCI Reflective Memory) module is a high-speed communication interface card designed for data sharing between multiple nodes in a distributed system. It utilizes a reflective memory technology, where data written to a local memory location is automatically and simultaneously replicated to corresponding memory locations on other nodes in the network. This provides a deterministic and low-latency method for inter-processor communication, making it suitable for demanding applications such as simulation, process control, and data acquisition. The specific model -111000 likely denotes a particular configuration or revision of this core module.
Product Parameters:
Based on available information for the cPCI-5565PIORC series:
- Form Factor: 3U CompactPCI
- Memory Capacity: Typically 128 MB or 256 MB SDRAM (check the specific datasheet for -111000)
- Reflective Memory Network Interface: Fiber Optic
- Bit Rate: 2 Gbit/s
- Latency: Very low, deterministic latency for data transfer
- PCI Bus Interface: 32/64-bit, 33/66 MHz, PCI specification 2.2
- PCI Express: 4 lanes at 2.5 Gbit/s
- Power Requirements:
- PMC: 0.7A typical, 1.5A max at +3.3 VDC; 0.7A typical, 1.8A max at +5 VDC
- Carrier: 19 mA @ 3 V; 24 mA @ 5 V; Total power 0.2 watts
- Operating Systems Support: Linux, VxWorks, Windows (driver availability may vary)
Specifications:
Again, the “-111000” suffix indicates a specific configuration, so the official datasheet for that exact part number is essential for precise specifications. However, general specifications for the GE cPCI-5565PIORC series include:
