GE SR469-P5-HI-A20-E
Here is the information you requested for the GE SR469-P5-HI-A20-E module in English:
Product Name: GE Multilin 469 Motor Management Relay
Product Description: The GE Multilin 469 is a microprocessor-based relay designed for the protection and management of medium and large horsepower motors and driven equipment. It integrates comprehensive motor protection features, fault diagnostics, power metering, and RTU (Remote Terminal Unit) functions into a single, economical draw-out package. It offers customizable overload curves, thermal modeling with RTD inputs for stator protection, and various communication protocols. The enhanced front panel includes an LCD display and keypad for local monitoring and configuration.
Product Parameters:
- Model Number: SR469-P5-HI-A20-E
- Series: 469 Motor Management Relay
- Control Power: 70 to 265 VAC at 48-62 Hz, 90 to 300 VDC
- Secondary CT Input: 5 A
- Analog Outputs: 4-20 mA
- Digital Inputs: Configurable for various functions (e.g., load shed, alarms, trips)
- Output Configuration: Six Electromechanical Form C relays
- Communication Ports: RS232, RS485 (baud rates: 300, 1200, 2400, 9600, 19200)
- Analog Current Output Accuracy: ±1% of full scale
- Timing Accuracy: ±0.5%
- Trickle Current: 2 to 5 mA
- RTD Sensing Current: 5 mA
Specifications:
- Certifications: ISO, UL, CE, CSA
- IP Class: IP20-X
- Humidity: Up to 95%, non-condensing
- Operating Temperature: Consult the manual (often -40°C to +70°C)
- Storage Temperature: -40°C to +80°C
- Mounting: Panel or 19-inch rack mount
