HONEYWELL MC-TDIY22

Product Name: Honeywell MC-TDIY22 Digital Input FTA (Field Termination Assembly)

Product Description:

The Honeywell MC-TDIY22 is a digital input Field Termination Assembly (FTA) designed to connect field-mounted digital input devices, such as switches, sensors, and limit switches, to Honeywell PLC or DCS systems, particularly within the Experion Process Knowledge System (PKS). It serves as an interface, converting signals from these devices into digital signals that can be processed by the control system. This module features compression terminals for easy and secure wiring and is designed for reliable operation in industrial automation and process control applications. Some versions are CE compliant and conformally coated for enhanced durability. It supports redundancy for increased system availability.

Key Characteristics:

• Digital Input FTA: Designed for terminating digital input signals from field devices.
• 24 VDC Input: Specifically designed for 24 VDC digital input signals.
• 32 Input Channels: Provides 32 independent digital input channels.
• Compression Terminals: Offers a convenient and secure wiring method.
• Redundancy Supported: Can be used in redundant configurations for higher system availability.
• Modular Design: Facilitates easy installation and maintenance.
• Hot-Swappable: Allows for module replacement without interrupting system operation.
• High Reliability: Built to withstand harsh industrial environments.
• Strong Compatibility: Compatible with various Honeywell PLC and DCS systems, especially Experion PKS.

Product Parameters:

• Manufacturer: Honeywell
• Model Number: MC-TDIY22
•
• Part Numbers: 51204160-175, 80366180-150, 80366180-175, 80363972-150 (various depending on specific configuration and compliance)
• Product Type: Digital Input Field Termination Assembly (FTA)
• Input Voltage Range: 15 to 30 VDC (24 VDC nominal)
• Number of Input Channels: 32
• Terminals: Compression terminals (Size B – 12 inches / 307 mm as a dimensional reference for the terminal block size)
• Weight: Approximately 0.55 kg (1.21 lbs) or 1000g (2.2 lbs) (sources vary slightly)
• Dimensions: Approximately 10.8 cm x 12.1 cm x 5.5 cm (4.25 in x 4.76 in x 2.17 in) (as per one source)

Specifications:

• Manufacturer: Honeywell
• Model: MC-TDIY22
• Series: Experion PKS (typically used with)
• Product Type: Digital Input FTA
• Input Signal Type: Digital, 24 VDC
