ICS TRIPLEX T8110B
Product Description: The ICS TRIPLEX T8110B is a Trusted TMR (Triple Modular Redundant) Processor Module designed for critical control and safety applications requiring high fault tolerance and reliability. It is part of the ICS TRIPLEX Trusted TMR system. The TMR architecture ensures that if one of the three redundant processing units fails, the other two continue to operate without interruption, providing bumpless control and maximizing system uptime. The T8110B features hardware-implemented fault tolerance (HIFT) for fast fault recognition and automatic handling. The “B” suffix in the part number (T8110B) indicates that this specific variant supports IRIG-B002 and 122 time synchronization and configurable RS422/485 connections.
Product Parameters (Typical):
- Processor: ARM Cortex-A8 (some sources mention ARM Cortex-A7 with 1GHz clock speed)
- Memory: 512MB RAM
- DRAM: 16 MB EDO 60 ns
- EPROM: 512 kB
- FLASH: 2 MB
- NVRAM: 128 kB
- Retained Variable Storage: 4 KB per variable (Booleans 1 byte, Analogues 4 bytes, Timers 5 bytes)
- Processor Clock: 100 MHz
- Voltage Range: 20 to 32V DC
- Operating Voltage: 24VDC
- Maximum Load: 80 W
- Heat Dissipation: 80 W
- Operating Temperature: -40°C to 70°C (some information mentions 0°C to 60°C)
- Non-operating Temperature: -25 to 70 °C
- Relative Humidity: 10-95% (non-condensing)
- Time Synchronization: IRIG-B002 and 122 (T8110B only)
Communication Ports: RS232 serial diagnostics port, Configurable RS422/485 connections (T8110B only)
- SOE Buffer: 1000 events, transferred to CI buffer of 4000 events
Specifications (Typical):
- Manufacturer: ICS TRIPLEX (now part of Rockwell Automation)
- Part Number: T8110B
- Series: Trusted TMR
- Type: TMR Processor Module
