ICS T8403

Product name: Trusted TMR 24V DC digital input module

Product Description:

ICS Triplex T8403 is a member of the Trusted family of input/output (I/O) modules. All Trusted I/O modules share common functionality and form factors. At the most general level, all I/O modules are connected to the Intermodule bus (IMB), which provides power and allows communication with the Trusted TMR processor. In addition, all modules have a field interface for connecting field wiring.

The T8403 Trusted® TMR 24 Vdc digital input module is a 40-channel digital input module with three-mode redundancy (TMR) for safety-critical applications that require high reliability and availability.

Product parameters:

Number of channels: 40
Input voltage range: 0V to 24V DC
Input current: 2 mA
Output type: Solid state
Output voltage: 24V DC

Output current: 200 mA
Response time: < 1 ms
SOE resolution: 1 ms
Power consumption: 10W
Operating temperature: -40°C to +70°C
Storage temperature: -55°C to +85°C
Humidity: 0% to 95% RH, non-condensing
Vibration: 5g RMS, 10 Hz to 500 Hz
Impact: 30g, 11ms half sinusoidal pulse
Dimensions: 12.7 x 8.9 x 2.3 cm (5 x 3.5 x 0.9 inches)
Weight: 340 g (12 oz)
Mounting method: DIN rail
Product Specifications:

Brand name: ICS Triplex
Model: T8403
