NI PXIE-4145

Product Description:

• The NI PXIe-4145 is a 4-channel source measure unit (SMU) module.
• It’s designed for high-pin-count applications, providing precise voltage and current sourcing and measurement capabilities.
• It features four-quadrant operation and integrated remote (4-wire) sensing for accurate measurements.
• This SMU is well-suited for tasks such as:
  • IV characterization of semiconductor devices.
  • Testing of integrated circuits.
  • General-purpose precision sourcing and measurement.
• It has high sampling rates, which helps to reduce test times, and capture transient characteristics of devices.
• It has a high-speed sequencing engine, which allows for the synchronization of the SMU’s with other instruments, such as switches, or high-speed digital test modules.

Product Parameters and Specifications:

• Key features and specifications include:
  • 4 channels.
  • ±6 V voltage range.
  • 500 mA current range.
  • High precision and accuracy.
