3500/22M 138607-01

The Bently Nevada 3500/22M 138607-01 module is a transient data interface module manufactured by Bently Nevada, Inc. that connects the Baylington 3500 Series monitoring System to General Electric’s System 1* machine management software. It is responsible for transmitting data between the two systems to achieve online monitoring and fault diagnosis of rotating machinery.

Product name resolution
Bently Nevada: Manufacturer, Baylington, Inc., a leading global supplier of rotating machinery monitoring and diagnostic equipment.
3500/22M: Product series and model, indicating that the module belongs to the 3500

series and is an interface module of the 22M series.
138607-01: Specific model of the product, representing specific specifications and functions.
Product description
The main features of the 3500/22M module include:

Data interface: The vibration and temperature data collected by the 3500 series monitoring System is transmitted to GE’s System 1* software.
Protocol conversion: Implements the conversion between different protocols to ensure data compatibility.
Data processing: The collected data is preliminarily processed to provide the basis for subsequent a

nalysis.
