3500/40M 176449-01

The Bently Nevada 3500/40M 176449-01 module is a proximity switch monitoring module from Baker Hughes (formerly GE Oil & Gas) under the Bently Nevada brand for vibration monitoring of rotating machinery. It protects and monitors rotating machinery by processing signals from proximity sensors from Bently Nevada, providing a variety of vibration and position measurements and comparing them with user-programmable alarms.

Product name resolution
Bently Nevada: a product brand focused on rotating machinery monitoring and protection.
3500/40M: Product series and model, indicating that the module belongs to the 3500 series and has 4 channels.
176449-01: Specific product identification code, used to distinguish different models.
Product description

The main functions of 3500/40M module include:

Signal processing: Processing signals from proximity sensors to extract vibration, position and other information.
Alarm function: The measured value is compared with the preset alarm value, and the alarm is issued when the set value is exceeded.
Data acquisition: Vibration data is collected to provide a basis for fault diagnosis.
Product parameters and specifications (please refer to the official data manual for details)
Number of channels: 4
Input signal: Bently Nevada proximity sensor signal
Measurement parameters: vibration amplitude, phase, radial vibration, eccentricity, REBAM, thrust position, differential thermal expansion, etc
Alarm type: Multiple alarm types can be configured
Communication interface: communicates with other modules of the 3500 system
