3BHB003688R0101

The ABB 3BHB003688R0101 module is a general purpose input/output module produced by ABB for industrial automation systems. It is mainly used to collect various signals in the field, such as digital quantities, analog quantities, etc., and convert them into standard digital signals, which are transmitted to PLC or other controllers. At the same time, the module can also receive the output signal of the controller, drive the actuator in the field, and realize the control of the pro

cess.

Product name resolution
3BHB003688R0101: This is the internal model number of ABB, which represents the specific model of the module. Different combinations of numbers and letters represent information such as the type, function, and version of the module.
Product description
As an important part of ABB’s automation system, the 3BHB003688R0101 module has the following main

functions:

Signal acquisition: collect the digital quantity (such as switching quantity, pulse quantity) and analog quantity (such as temperature, pressure) signals of the site.
Signal conversion: the collected signal is converted into a standard digital signal, which is convenient for PLC processing.
Signal output: According to the PLC instructions, drive the field actuator to achieve the process control.
Flexible configuration: The input/output type and quantity of modules can be flexibly configured according to different application requirements.
