3BSE015488R1 NAMC-11

3BSE015488R1 is a NAMC-11 control module produced by ABB. It is usually used in ABB’s ACS600 series inverter as one of the core control components of the inverter. NAMC-11 module is responsible for handling the control logic, parameter setting, fault diagnosis and other

functions of the inverter, and is a key component of the normal operation of the inverter.

Product name resolution
3BSE015488R1: This is the specific model assigned by ABB for the module, which contains information about the module version, production batch, etc.
Namc-11: is the family name of the module, indicating that it belongs to the NAMC family of control modules.
Product description

The NAMC-11 module acts as the “brain” of the inverter and its main functions include:

Control logic: to achieve the inverter start, stop, acceleration, deceleration and other control.
Parameter setting: The user can set various parameters of the inverter through the module, such as output frequency, torque, overload protection, etc.
Fault diagnosis: Monitor the operating status of the inverter, when the fault occurs, it will send an alarm signal and record the fault information.
Communication interface: provides a variety of communication interfaces, such as CANopen, Modbus, etc., to facilitate communication with the host computer.
Product parameters and specifications (typical values, refer to the product data sheet)
Operating voltage: DC voltage, the specific value depends on the inverter model.
Operating temperature: Industrial grade temperature range
Size: depends on inverter model and installation method
Interfaces: CANopen, Modbus, etc
