8200-1302

The 8200-1302 module is typically a component in a turbine control system manufactured by Woodward. Woodward is a leading global innovator in control solutions for a wide range of applications in the energy, industrial and aerospace sectors.

Product name and description

Product name: Woodward 505D Digital governor turbine control system module
Product Description: 8200-1302 module is a part of Woodward 505D series digital governor, mainly used to control the turbine speed, power and other parameters to meet the requirements of different working conditions. This module is usually integrated in the turbine control system and works in concert with other modules to achieve precise control of the entire system.
Product parameters and specifications

Since the specific parameters of the 8200-1302 module will vary according to different configurations and application scenarios, the following are some possible parameters:

Input signal: speed feedback signal, pressure signal, temperature signal, etc.
Output signal: control valve signal, alarm signal, etc.
Communication interface: CAN bus, digital I/O, etc.
Operating voltage: 24V DC or other.
Operating temperature range: -20℃ to +70℃ or other.
Protection level: IP20 or higher.
Size: According to the specific model.
Product function
Speed control: Precisely control the turbine speed by adjusting the opening of the control valve.
Power control: Adjust turbine output power according to load demand.
Protection function: Provides overspeed, underspeed, overvoltage, undervoltage and other protection functions to ensure the safe operation of the device.
Self-diagnosis function: it can monitor the module’s own status in real time and send an alarm signal.
Communication function: Through the communication interface with the host computer or other devices for data exchange
