Product name: HONEYWELL CC-PCNT01 module, also known as the controller module, is an I/O module produced by Honeywell for C300 controllers. The module has the following features:

High performance: The use of advanced processors and algorithms, can achieve high-speed, high-precision counting functions.
Flexible: Support a variety of counting modes to meet a variety of application requirements.
Reliable: Industrial grade design, can withstand harsh working environment.
Product parameters:

Parameter value unit
Module Type Controller module
Applicable controller C300
Count channels 4
Counting frequency up to 50 MHz
Resolution programmable
Input type Single pulse, double pulse, encoder
Output type Pulse, Interrupt, event
The power supply requires 24V DC
Operating temperature -40°C to 85°C
Storage temperature -55°C to 100°C
Humidity 5% to 95% non-condensing
Vibration 5 Hz to 500 Hz, peak acceleration 0.5 g
Shock 10 g/20 ms half sine wave
Dimensions 116 mm x 60 mm x 35 mm
Weight 0.4kg
