A-B 1394C-SJT22-A

The A-B 1394C-SJT22-A is A powerful servo controller that supports up to four axes and works as a speed or torque controller. Its analog module function and 10-volt DC analog interface make it suitable for a wide range of industrial automation applications. In addition, the servo controller is equipped with intelligent power supply, EMI filtering and improved terminal features to ensure its stable and reliable performance.

The module also has diagnostic functions, including current monitor, thermal overload detection and feedback signal monitor, to facilitate the operation and maintenance of the equipment. The digital-to-analog converter (DAC) board performs digital-to-analog conversion in the controller and is capable of analog conversion of 12-bit positive true offset binary input code words with an output range of -10 to +10 volts, providing a high-resolution feedback signal to the sensor12.

Product parameters and specifications:

Electrical parameters: Capacitance 660 farad, inductance 500 Henri. At DC voltage, the continuous outp

ut current is 33.8 amps, the continuous output power is 22 kW, and the peak current is 200.0 amps 12.
Input voltage: Supports 24 volt AC power supply with disconnect function, fuse box, provides 24 volt DC power for motor brake and hot contact 12.
Operating environment: It can operate at 324 to 528 volts, 50 to 60 Hertz AC, with an efficiency of 98%. The module is suitable for installation on a flat, stable vertical surface. The installation panel must have minimal shock and vibration, and the environment must be free of moisture, oil, dust, and corrosive gases
