A-B 1394C-SJT22-A

The Allen-Bradley 1394C-SJT22-A is a high-performance servo controller that belongs to the Allen-Bradley Series C system module. It is widely used in industrial automation to precisely control the speed and position of motors. The module has powerful function and reliability, and can meet various complex motion control requirements.

Main feature
Multi-axis control: Supports control of up to four axes and can control multiple motors at the same time.
Speed and torque control: can work as a speed or torque controller, flexible to adapt to different application scenarios.
Analog module function: Equipped with analog module function and 10 volt DC analog interface for easy communication with other devices.
Automatic tuning: Equipped with Bulletin 1201 HMI module, allowing automatic tuning and fast start.
High efficiency: Operating at AC of 324 to 528 volts and 50 to 60 Hertz, the efficiency reaches 98%.
Diagnostic function: With current monitor, thermal overload detection and feedback signal monitor and other diagnostic functions.
Main parameter
Power: 22 kW
Input voltage: 324-528 V AC, 50-60 Hz
Output current: continuous output current 33.8 amps, peak current 200 amps

Communication interface: analog interface, CANopen, etc
Other parameters: Refer to the product data manual
Application field

Automated production line: used to control various mechanical equipment on the production line, such as conveyor belts, robots, etc.
Packaging machinery: Used to control the servo motor in the packaging machinery to achieve precise packaging action.
Machine tool: Used to control the spindle and feed shaft of the machine tool to achieve high-precision machining.
