A-B 1734-SSI Input module

Today's recommended products: NVIDIA H100 PCIE NVIDIA H800 PCIE LAM 839-101612-885 LAM 839-101612-887 LAM 719-101612-885 LAM 719-101612-887 Many in stock, first come first served, first-hand source, channel Contact: Han Fangting Sales Manager Mobile :18030042035 QQ: 748141623 Email: 748141623@qq.com Web site :www.changxindcs.com www.changxinsz.com We operate ABB, GE aereration, A-B, Honeywell, KUKA, SCHNEIDER, Bentley, TRICONEX Invensys, WOODWARD, FOXBORO, WESTINGHOUSE, and MOTOROLA MOTOROLA, KEBA, KOLLMORGEN, EMERSON, HIMA dark horse, industrial and commercial energy storage, container energy storage, household light energy storage, (peak cutting, valley filling, backup power supply) can be contacted if necessary. Country of Origin: USA Moq :1 piece Packaging: new raw materials and individual packaging Delivery time :2-3 working days Payment method: Bank transfer, Western Union

+86-18030042035

748141623@qq.com

A-B 1734-SSI

The Allen-Bradley 1734-SSI module is an input module for collecting data from industrial grade absolute position encoders. It communicates with the encoder through the standard SSI protocol, and converts the absolute position information fed back by the encoder into a digital signal that can be recognized by PLC, so as to realize the high-precision measurement and control of the device position. The module is widely used in various automation systems requiring precise position control, such as CNC machine tools, robots, packaging machinery, etc.

Product parameters and specifications:
Number of channels: One SSI channel
Supply voltage: 10-28.8VDC

POINTBus current: 110 MA
Interface type: SSI
Resolution: determined by the encoder

Operating temperature: 0℃ to 55℃
Dimensions: 56 x 12 x 75.5mm
Main functions:
SSI signal acquisition: The absolute position information of the encoder is received through the SSI interface.
Data conversion: The SSI signal is converted into a digital signal that the PLC can recognize.
Position feedback: Provide real-time position feedback for PLC to achieve closed-loop control.
