A-B 1746-A10

The A-B 1746-A10 module is A rack module for the SLC 500 series PLC manufactured by Rockwell Automation (Allen-Bradley). It is a chassis used to house and connect various SLC 500 series I/O modules, processor modules, etc., to form a complete PLC system.

Product description
The 1746-A10 rack provides 10 slots for installing different modules, such as digital input module, digital output module, analog input module, analog output module, communication module, etc. These modules are connected to the rack through the backplane bus for data exchange and control.

Product parameters and specifications
Number of slots: 10
Dimensions: Approximately 16.9 x 6.8 x 5.8 inches
Weight: Approx. 1.45kg (excluding module)
Backplane current: 10A for 5.1V DC and 2.88A for 24V DC
Mounting method: DIN rail mounting
Compatibility: Compatible with Allen-Bradley SLC 500 series modules
Main function

Module load: Multiple slots are provided for mounting various SLC 500 series modules
Data connection: Each module is connected through the backplane bus to realize data exchange
System integration: As the core component of the PLC system, to achieve the integration of the entire system
Application scenario
The 1746-A10 rack is widely used in a variety of industrial automation control systems, such as:

Machine control: control machine start, stop, movement, etc
Process control: control various parameters in the production process
