A-B 1746-NI4

Allen-Bradley 1746-NI4 is an analog input module designed for the SLC 500 series Programmable Logic controllers (PLCS). It can convert analog signals from external devices (such as temperature, pressure, flow, etc.) into digital signals that can be recognized by PLC, so as to realize the acquisition and processing of analog data.

Product parameters and specifications

Number of channels: 4
Input type: Can be configured as voltage or current input
Resolution: 16 bits
Isolation voltage: 500 VDC
Signal range: The specific range depends on the configuration, refer to the product manual
Accuracy: ±0.1%
Operating temperature: 0°C ~ 55°C
Mounting method: DIN rail mounting
Main function
Analog signal acquisition: Converts external analog signals into digital signals.
Signal isolation: Provides isolation between input and output to improve system reliability.
Flexible configuration: The input type and range of each channel can be configured as required.
Application field
Process control: Used to capture process variables such as temperature, pressure, flow, etc.
Data acquisition: Used to collect a variety of analog data, data analysis and processing.
