A-B 1746-NI8

The 1746-NI8 module is mainly used to convert analog signals (such as temperature, pressure, flow, etc.) into digital signals that PLC can recognize. It is usually installed on the rack of the SLC 500 series PLC, by connecting various sensors to collect the analog information of the field and transmit it to the PLC for processing.

Product parameters and specifications (typical values, please refer to the product manual for specific parameters)
Type: Analog input module

Number of channels: 8
Input type: ±10V DC, ± 20mA
Resolution: 16 bits
Sampling rate: Configurable

Isolation: Channels are isolated from each other
Mounting method: DIN rail mounting
Note: Specific parameters may vary by production batch and configuration, please refer to the official data of Rockwell Automation.

Main feature
High precision: 16 bit resolution to ensure the accuracy of measurement results.
Multi-channel: 8 independent input channels, improve the flexibility of the system.
Isolation design: improve the anti-interference ability of the system.
Configurable: The sampling rate and filtering parameters can be configured according to different application requirements.
Application field
1746-NI8 modules are widely used in various industrial automation fields, such as:

Process control: Measurement of temperature, pressure, flow and other process variables.
Environmental monitoring: Monitoring environmental parameters such as temperature and humidity.
Data acquisition: The analog signal is converted to digital signal for PLC analysis and processing.
