A-B 1746-OBP16/C

Allen-Bradley 1746-OBP16/C is an output module designed for the SLC 500 series PLC. It is mainly used to convert the digital signal from the PLC into a control output, driving various types of loads, such as relays, solenoid valves, contactors, etc., to achieve the control of external equipment.

Product parameters and specifications:

Number of channels: 16
Output type: Relay output
Contact form: normally open or normally closed (configurable)
Load capacity: The load capacity of each channel varies according to the specific model

Power supply: From the backplane
Mounting method: DIN rail mounting
Main features:
High density: 16 output channels in a compact space.
Flexible configuration: Parameters such as output type and load type can be configured through software.
Isolation: Electrical isolation between channels improves system reliability.
Diagnosis function: Provides channel-level diagnosis to facilitate fault diagnosis.
High reliability: Industrial grade design, suitable for harsh industrial environment.
Application field:
Industrial automation: widely used in a variety of industrial automation control systems, control motors, valves, pumps and other equipment.
Machine control: used to control various actions of the machine, such as starting, stopping, direction control, etc.
Process control: Used to control process equipment, such as heaters, coolers, etc.
Note:
Load matching: When selecting the output module, it should be matched according to the type of load and rated current.
Wiring: Wiring should be carried out in strict accordance with the instructions to avoid wrong connection.
Overload protection: The module has overload protection function, but it is still necessary to pay attention to the rated current of the load.
Ambient temperature: The working ambient temperature shall comply with the requirements of the product manual.
