A-B 1756-IF16/A

The Allen-Bradley 1756-IF16/A module is a high-performance analog input module for Rockwell Automation’s ControlLogix platform. It is mainly used to collect analog signals in industrial sites, such as temperature, pressure, flow, etc., and convert these analog signals into digital signals, so as to realize the monitoring and control of industrial processes. Compared to the 1756-IF16 module, the 1756-IF16/A module typically has higher accuracy, faster sampling rates, or other enhancements.

Main function

Analog input: Collect analog signals from industrial sites and support a variety of input types, such as voltage and current.
Signal conditioning: The collected analog signal is filtered, amplified and other processing to improve the signal quality.
Signal conversion: the analog signal is converted to digital signal, which is convenient for PLC processing.

Fault diagnosis: The module has a self-diagnosis function, which can detect and report faults.
Product parameters (part, detailed parameters please refer to the official materials)
Number of channels: 16 analog input channels
Input type: Support a variety of input types, such as ±10V, 0-10V, 0-5V, 4-20mA, etc
Resolution: High resolution, higher than the 1756-IF16 module
Sampling rate: Higher sampling rate to capture faster signal changes
Isolation voltage: high to ensure system safety
Mounting method: DIN rail mounting
Application field
Process control: Used to collect process variables, such as temperature, pressure, flow, etc., to achieve process control.
Data acquisition: Used to collect on-site data for data analysis and storage.
Vibration monitoring: Due to the higher sampling rate, it can be used for applications that require a fast response, such as vibration monitoring.
Fault diagnosis: By monitoring analog signals, equipment faults are detected in time.
