A-B 1756-IF16

The Allen-Bradley 1756-IF16 module is a high-performance analog input module for Rockwell Automation’s ControlLogix platform. It is mainly used to collect analog signals in industrial sites, such as temperature, pressure, flow, etc., and convert these analog signals into digital signals, so as to realize the monitoring and control of industrial processes. The module is usually connected to various types of sensors that convert continuous physical quantities into digital signals that the PLC can process.

Main function

Analog input: Collect analog signals from industrial sites and support a variety of input types.
Signal conditioning: The collected analog signal is filtered, amplified and other processing to improve the signal quality.
Signal conversion: the analog signal is converted to digital signal, which is convenient for PLC processing.
Fault diagnosis: The module has a self-diagnosis function, which can detect and report faults.
Product parameters (part, detailed parameters please refer to the official materials)

Number of channels: 16 analog input channels
Input type: Support a variety of input types, such as ±10V, 0-10V, 0-5V, 4-20mA, etc
Resolution: High resolution, accurate acquisition of analog signals
Sampling rate: High sampling rate to meet the measurement requirements of high-speed dynamic processes
Isolation voltage: high to ensure system safety
Mounting method: DIN rail mounting
Application field
Process control: Used to collect process variables, such as temperature, pressure, flow, etc., to achieve process control.
Data acquisition: Used to collect on-site data for data analysis and storage.
Fault diagnosis: By monitoring analog signals, equipment faults are detected in time.
