A-B 1756-IF16

The Allen-Bradley 1756-IF16 module is an important module in the ControlLogix series of controllers manufactured by Rockwell Automation. It is mainly used to collect analog signals in industrial processes, such as temperature, pressure, flow, etc., and convert them into digital signals for PLC processing and control. The module has the characteristics of high precision, high reliability and easy configuration, and is widely used in various industrial automation systems.

Main feature
High precision: provides high precision analog measurement to meet the measurement needs of various industrial processes.
Multi-channel: usually has 16 analog input channels, which can collect multiple signals at the same time.
Flexible configuration: Different input ranges and filtering functions can be configured to adapt to various application scenarios.
High reliability: Industrial design, with high anti-interference ability and stability.

Easy integration: Can be easily integrated into the ControlLogix system.
Product parameters and specifications (some parameters, please refer to the official information for details)
Parameter Name Parameter Value Unit description
Input channels 16 Indicates the number of analog input channels
Input Signal type Voltage and current Support multiple input signal types
Input Range Configurable V/mA Configure the input range based on the actual application
High resolution digital precision
