A-B 1756-IF8

The Allen-Bradley 1756-IF8 module is an analog input module for the ControlLogix platform from the Allen-Bradley brand of Rockwell Automation. It is mainly used to collect analog signals in industrial sites, such as temperature, pressure, flow, etc., and convert these analog signals into digital signals, so as to realize the monitoring and control of industrial processes.

Main function

Analog input: Collect analog signals from industrial sites, such as 4-20mA current signals, voltage signals, etc.
Signal conditioning: The collected analog signal is filtered, amplified and other processing to improve the signal quality.
Signal conversion: the analog signal is converted to digital signal, which is convenient for PLC processing.
Fault diagnosis: The module has a self-diagnosis function, which can detect and report faults.
Product parameters (part, detailed parameters please refer to the official materials)

Number of channels: 8 analog input channels
Input type: Usually 4-20mA current signal or voltage signal
Resolution: High resolution, accurate acquisition of analog signals
Isolation voltage: high to ensure system safety
