A-B 1756-IF8

The Allen-Bradley 1756-IF8 module is an analog input module for the ControlLogix series PLC manufactured by Rockwell Automation. It is mainly used to collect analog signals from industrial sites, such as temperature, pressure, flow, etc., and convert these analog signals into digital signals for PLC processing. The module has the characteristics of isolated input, high precision and flexible configuration, and is widely used in the field of industrial automation.

Main function

Analog signal acquisition: Acquisition of 4-20mA or 0-10V analog signals.
Signal conversion: Converts an analog signal to a digital signal.
Isolation protection: Each channel has an isolation protection function to prevent interference.
Flexible configuration: A variety of configurations can be performed through software, such as input range, filtering, etc.
Product parameters and specifications (some parameters, please refer to the official data)

Model: 1756-IF8
Number of channels: 8
Input type: Analog input
Input range: 4-20mA or 0-10V
Resolution: High precision
Sampling rate: Configurable
Power supply: 24VDC
Isolation voltage: 1500VAC
Mounting method: DIN rail
Application field
Process control: acquisition of temperature, pressure, flow and other analog quantities.
Industrial automation: collect motor current, position and other signals.
Data acquisition system: acquisition of analog data of various industrial sites.
peculiarity
High accuracy: Provides high precision data acquisition.
Multi-channel: 8 channels, can collect multiple analog signals at the same time.
Flexible configuration: It can be configured according to different application requirements.
High reliability: Industrial grade design, suitable for harsh environments.
