A-B 1756-OF8
Information about the A-B 1756-OF8 module is as follows:
Product Name:
Allen-Bradley (A-B) 1756-OF8 ControlLogix Rockwell Analog Output current/Voltage Module 1234.
Product Description:
The A-B 1756-OF8 is an electronic relay designed for use in various control and automation systems in the industrial and power sectors. With high reliability, accuracy and flexibility, it can be effectively applied to a variety of control tasks. The module has analog output current/voltage function, can convert the signal in the digital control system to analog output signal, suitable for industrial automation field, such as control motor speed, temperature regulation and other applications 1234.
Product parameters:
Voltage range: Standard voltage is 230 VAC, 50/60 Hz, but other voltages can be supported, depending on configuration 1.
Output capacity: Output ratings are ±10 volts or 0 to 20 mA, and voltage or current output ranges from -10 to 10V or 4 to 20 mA23.
Signal resolution and power consumption: The signal resolution is 15 bits at 21 mA and 15 bits at 10.4 volts. The large power consumption of the circuit is 5.8 watts, and the total fixed power is also 5.8 watts 23.
Backplane current: at 24 volts DC, the backplane current is 210 mA; At 5.1 volts, the backplane current is 150 mA DC volt3.
Specifications:
Number of channels: There are 8 independent analog output channels, each of which can be configured individually 4.
