A-B 1769-HSC

The AB 1769-HSC module is a high speed counter module for the CompactLogix series PLC manufactured by Rockwell Automation (Allen-Bradley). It is mainly used to measure the speed, position or count of high-speed moving parts, and is commonly used in motion control, servo systems, and applications requiring high precision counting.

Product description

The 1769-HSC module offers two or four four-quadrant (ABZ) differential inputs that can be connected to various types of encoders or pulse generators. The module has a high-speed counter inside, which can accurately count the input pulse signal. In addition, the module also provides a variety of counting modes and control functions to meet different application requirements.

Product parameters and specifications
Input type: 2 or 4 four-quadrant (ABZ) differential inputs
Counting frequency: high-speed counting, please refer to the product data manual for specific frequency
Count mode: Support a variety of count modes, such as incremental count, direction count and so on
Control function: Provides a variety of control functions, such as zero reset, direction control, etc
Output: Provides output of status bits and count values
Mounting method: DIN rail mounting
Ambient temperature: The module can operate within a certain temperature range
Other parameters: filtering function, diagnosis function, etc
Main feature
High-speed counting: Capable of processing high-speed counting signals.
Multi-function: Support a variety of counting modes and control functions.
High precision: High counting accuracy.
Flexible configuration: It can be flexibly configured through programming software.
Easy installation: DIN rail installation is convenient and fast.
