A-B 2711P-RP2

The Allen-Bradley 2711P-RP2 module is an embedded logic module from Rockwell Automation’s Allen-Bradley brand, designed for the PanelView Plus human Machine interface (HMI). It integrates powerful logic processing capabilities into the HMI, enabling the HMI not only to display data, but also to perform complex control tasks, thereby simplifying system architecture and reducing costs.

Main function

Embedded logic control: Execute logic programs locally on the HMI without additional PLC.

Data processing: data collection, processing and display.
Communication: Communication with other devices (such as PLCS, drives, etc.).
Alarm management: Monitor process variables and generate alarm information.
Recipe management: Manage and invoke different production recipes.
Product parameters (part, detailed parameters please refer to the official materials)
Processor: A high-performance processor that provides powerful computing power.
Memory: 128MB RAM and 128MB Flash for storing programs and data.
Communication interface: Supports multiple communication protocols (such as DH+, Ethernet/IP) to connect to other devices.
Programming language: Supports programming software from Rockwell Automation.
Power supply: 24VDC
Application field
Process control: Simple logic control and data display on the HMI.
Machine control: Used to control small machines or equipment.
Data acquisition: Field data is collected and displayed on the HMI.
Recipe management: Manage and invoke different production recipes.
peculiarity
Easy to use: Provides an intuitive programming environment for users to develop applications.
Flexible expansion: Supports multiple communication protocols and can be integrated with different devices.
High reliability: Industrial grade design, suitable for harsh industrial environment.
