A-B 80026-044-06-R

The A-B 80026-044-06-R module is A switching power module under the Allen-Bradley brand of Rockwell Automation. It is mainly used to provide stable power supply for programmable logic controllers (PLCS) and other automation equipment.

Product description

This module is compact and suitable for use in control cabinets where space is limited. It converts alternating current to direct current and provides multiple output channels to meet the power needs of different devices. This module is usually mounted on a PLC rack and is used in conjunction with other I/O modules.

Product parameters and specifications

Model: 80026-044-06-R
Brand: Allen-Bradley (Rockwell Automation)
Type: Switching power module
Input voltage: 24-60 VDC
Output voltage: 6 channels, 20 VDC each
Output current: 3A per channel
Isolation voltage: 3000 VDC
Operating temperature: -40℃ to 70℃
Dimensions: 4.65 x 1.38 x 3.43 inches (118 x 35 x 87 mm)
Weight: 0.44 lb (0.20 kg)
Certification: UL, CSA
Warranty: 5 years
Main feature
Compact design: Saves installation space
Multi-channel output: Meet the power requirements of a variety of devices
High reliability: Industrial grade design for harsh environments
Easy installation: Modular design, easy installation
Application field
Industrial automation: Power supply for PLC, HMI, inverter and other automation equipment
Process control: Used for various devices in process control systems
Machine automation: Provide power for various automated machines and equipment
Working principle
The module converts the input DC voltage through the internal circuit to produce multiple stable DC output voltages. The output voltage and current can meet the requirements of different load equipment.

Matters needing attention
Power input: Ensure that the input voltage is within the specified range.
Load matching: The output load should conform to the rated current of the module.
Heat dissipation: The module must be installed in a well-ventilated environment.
