AB 1762-OW16

The Allen-Bradley 1762-OW16 is an expansion module for the MicroLogix family of small programmable logic controllers (PLCS). It provides 16 separate relay output channels that can be used to control external devices such as motors, valves, lights, etc. The module is compact, easy to install, and has overload protection, short circuit protection and other safety functions to ensure the reliable operation of the PLC system.

Product parameters and specifications:

Number of output channels: 16
Output type: Relay output
Contact form: normally open contact (refer to the product manual)
Load capacity: Depends on the specific model and load characteristics
Control mode: PLC control

Mounting method: DIN rail mounting
Operating temperature: 0℃ to 55℃
Main functions:
Output control: Control the on-off of external equipment according to the instructions of PLC program.
Isolation protection: there is electrical isolation between the relay output and the PLC control circuit to improve the safety of the system.
Overload protection: When the load current is too large, the relay will automatically disconnect, protecting the module and the load.
Short-circuit protection: When the output short-circuit occurs, the relay will automatically disconnect to prevent damage.
