ABB 3BHE014185R0001

The ABB 3BHE014185R0001 module is a high performance industrial module that supports predetermined communication rates in the standard specification and can be manually set or rate adaptive via a drop switch to ensure rate consistency with all electrical interfaces. In addition, it also has six two-color LED status indicators and power failure relay output alarm function, which can monitor the working status of the module in real time. The module also has an industrial-grade design, including electrical interface 4000V

 lightning protection, 1.5A overcurrent and 600W surge protection, as well as DC9-36V wide redundant dual power supply and DC1500V power supply isolation, ensuring stable operation in a variety of harsh environments. In addition, the module also supports the Profibus DP bus standard and has a variety of communication rate options to adapt to different communication needs. In terms of electrical connections, it complies with the VDE 0100 directive and needs to be grounded as prescribed to protect personnel against electric shock 124.

Product parameters:

Power supply: Dual power supply redundant input, DC(9-36)V, typical DC24V, power consumption less than 4W13.
Communication rate: Supports a variety of rates, including 9.6kBit/s, 19.2 kBit/s, 45.45kBit/s, etc. 12.
Lightning protection and overcurrent protection: with 4000V lightning protection and 1.5A overcurrent protection 12.
Interface: 9-pin Sub_D jack connector, compliant with Profibus DP protocol specification 1.
