ABB 3BHE023784R0001

The ABB 3BHE023784R0001 module is an industrial automation component produced by ABB and commonly used in its ACS800 series of frequency converters. This is usually a drive circuit module used to drive the power semiconductor devices (such as IGBTs) inside t

he inverter to achieve precise control of the motor.

Product description
Function: Drive the internal power device of the inverter to achieve voltage and frequency control of the motor
Application: ABB ACS800 series inverter
Features: High reliability, high efficiency, programmable
Main parameters and specifications
Model: 3BHE023784R0001
Brand: ABB
Series: ACS800
Type: Driver circuit module

Interface: The specific interface type and number depends on the inverter model and configuration
Voltage: According to the rated voltage of the inverter
Current: According to the rated current of the inverter
Control mode: The control signal is issued by the inverter main control board, and the drive module drives the power device according to the signal
Protection level: Depending on the application environment, the protection level is also different
Product characteristics
High reliability: Designed for industrial environments with high reliability
High efficiency: can improve the overall efficiency of the inverter
Programmable: Can be configured according to different application requirements
Modular design:
