ABB 3HAC022999-001

The ABB 3HAC022999-001 module, based on available information, is clearly identified as a process cable assembly. This indicates that it is not a separate electronic module, but a cable assembly for connecting process meters and automation systems.

Process cable assemblies typically include:

Multi-core cable: used to transmit a variety of signals, such as analog signals, digital signals, power supplies, etc.
Connector: Interface for connection to process instrumentation and automation systems.
Shield: Provides electromagnetic shielding and mechanical protection.
Main function
Signal transmission: The measurement signal of process instruments (such as temperature sensors, pressure sensors, etc.) is transmitted to the automation system.
Power supply: Supply the required power to the process meter.
Signal isolation: In some cases, a signal isolation function is provided to protect the device.
Product parameters (may include, subject to official data)
Cable length: Customized according to the specific application.
Number of conductors: Depends on the number of signals.
Conductor cross section: depends on load current and signal frequency.
