ABB 5SHX1445H0001

ABB 5SHX1445H0001 IGCT module
Module 5SHX1445H0001

Product Description:

The ABB 5SHX1445H0001 module is ABB’s high-performance, highly reliable integrated gate commutated thyristor (IGCT) module designed for high-voltage, high-power power conversion and control applications. It combines the high-speed switching characteristics of the IGBT (insulated gate bipolar transistor) with the high blocking voltage and low on-loss characteristics of the GTO (gate off thyristor) to achieve efficient and stable power control. The module has the following features:

High performance: Using advanced IGCT chip, fast switching speed, low loss, can withstand high voltage and high current.
High reliability: Redundant design and strict quality control measures ensure long-term reliable operation.
Easy to use: Provides intuitive interface and rich diagnostic tools, easy to install, maintain and operate.
Flexibility and scalability: Multiple configuration options are supported to meet different application requirements.
Product parameters:

Type: IGCT module
Voltage: 4500 V
Current: 1445 A
Switching frequency: up to 2 kHz
Power consumption: < 3.5kW
Operating temperature: -40°C to 85°C
Storage temperature: -55°C to 125°C
Humidity: 5% to 95% (non-condensing)
Protection level: IP67
Specifications:

Dimensions: 305 mm x 233 mm x 120 mm
Weight: 20 kg
