ABB 5SHY35L4520

The ABB 5SHY35L4520 module is an asymmetric IGCT module mainly used in the field of power electronics. IGCT (insulated gate bipolar transistor) is a kind of high-power semiconductor device, which has the characteristics of fast switching, high voltage, high current, etc., and is widely used in power conversion, motor drive and other applications.

Product description

The 5SHY35L4520 module is part of ABB’s family of power semiconductors and its core component is IGCT. The module has the characteristics of high reliability, high efficiency and low loss, and is suitable for various industrial applications.

Product parameters and specifications (some parameters, please refer to the official information)
Model: 5SHY35L4520
Brand: ABB
Type: Asymmetric IGCT module
Voltage level: 4500V
Current level: 4000A

Main features:
High voltage: Suitable for high pressure applications
High current: can carry high current
Fast switching: Improves system efficiency
No continuous current switch: No additional continuous current circuit is required
Suitable for medium frequency applications (<1kHz)
Main application
Power conversion: Used for power converters, inverters and other equipment
Motor drive: For high power motor drive system
Industrial heating: Used in industrial furnaces and other heating equipment
Power system: used in power system reactive power compensation, harmonic suppression, etc
