ABB 5SHY35L4520

ABB 5SHY35L4520 module description in Chinese
Product overview
The ABB 5SHY35L4520 module is an IGBT module, a power semiconductor device. The Insulated Gate Bipolar Transistor (IGBT) is a power semiconductor device that combines the high current drive capability of a bipolar transistor with the high input impedance of a MOSFET. ABB 5SHY35L4520, as an IGBT module, is mainly used in applications requiring high current and high frequency switches, such as frequency converters, inverters, motor drives, etc.

Product name and description
Product name: ABB 5SHY35L4520 IGBT module

Product Description: This module is a high-performance IGBT module, with fast switching speed, low on-voltage drop and other characteristics, suitable for industrial automation, power electronics and other fields.
Main parameters and specifications
Model: 5SHY35L4520
Type: IGBT module

Rated current: Depending on the specific model and operating conditions, usually tens of amps to hundreds of amps.
Rated voltage: Depending on the specific model and operating conditions, usually several hundred volts to several thousand volts.
Switching speed: Very fast, suitable for high frequency switching applications.
Package: TO-247 or other package form suitable for power devices.
Main function
Power switch: Used as a switching element in power electronic circuits to control power.
Current conversion: Converting direct current to alternating current, or alternating current to direct current.
Frequency conversion: Used for frequency converter to control the speed of the motor.
