ABB ACS800-104-0320-5+E205+Q950+V991

The ABB ACS800-104-0320-5+E205+Q950+V991 is a general-purpose inverter manufactured by ABB in the ACS800 series. It is mainly used to control the speed and torque of three-phase asynchronous motor, and is widely used in industrial automation, building automation and other fields.

Product name resolution
ACS800: A series of ABB frequency converters that stand for universal frequency converters.

104: May represent the rated power of the inverter or other specific parameters.
0320-5: May represent the output voltage range of the inverter or other parameters.
E205, Q950, V991: These are option codes that represent some additional features or configurations of the inverter, such as brake units, filters, etc.
Product characteristics

High performance: Provides precise speed control and torque control.
High reliability: Advanced control technology and high quality materials are used.
Easy to use: provides a variety of control methods and rich functions.
Flexible configuration: Flexible configuration based on different application requirements.
Perfect protection function: overload, overvoltage, overcurrent and other protection functions.
Main function
Variable frequency speed regulation: Adjust the motor speed by changing the power frequency of the motor.
Vector control: Achieve high performance torque control.
PID control: to achieve closed-loop control, improve the stability of the system.
A variety of communication modes: support a variety of communication protocols, easy to communicate with the host computer.
Product parameters (typical values, specific parameters refer to the product manual)
Parameter possible value (according to specific model)
Input voltage 3 phases 380V-480V
The output current depends on the model, for example, 32A
Control mode V/f control, vector control
Brake unit optional
Filter selectable
Communication interfaces Modbus RTU, Profibus DP, etc
