ABB ACU-01B

The ABB ACU-01B module is an air control unit designed by ABB for its robotic systems. It is mainly used to control the pneumatic system of the robot, adjust the air pressure, control the cylinder action, and provide power for the movement and opera

tion of the robot.

Product name resolution
ABB: ABB Group, a leading global power and automation technology group.

ACU: Abbreviation of Air Control Unit, namely, air control unit.
01B: Model identification, which represents the specific version and functionality of the module.
Product description
As a key component of ABB’s robotic system, the ACU-01B module has the following key functions:

Air pressure regulation: Precise control of the air pressure supplied to the robot actuator through the built-in pressure regulator.
Gas path control: control the expansion of the cylinder, clamping of the fixture and other actions to achieve various operations of the robot.
Fault diagnosis: Monitor the working status of the gas system and provide fault diagnosis information.
