ABB DSDP150

The ABB DSDP150 module is a module produced by ABB for pulse counting and positioning. It is typically integrated into ABB’s Advant OCS systems for a variety of industrial automation applications.

Product name
ABB pulse counting and positioning module

Product description
The DSDP150 module is mainly used to collect and process pulse signals from external devices, such as encoders, and convert them into digital signals that can be used for control systems. It enables accurate pulse counting, frequency measurement and position control. The module is commonly used in applications requiring high precision motion control, such as robots, machine tools, packaging machinery, etc.

Product parameters and specifications (typical values, subject to official data)
Input signal: Pulse signal (usually 12V DC)
Counting frequency: up to 10kHz
Function: pulse counting, frequency measurement, position control
Interface: Generally compatible with ABB Advant OCS systems
Operating temperature: -10℃ to +50℃
Protection Class: IP20 (specific model may be different)
Main function
Pulse counting: Counts pulses from external devices with high precision
Frequency measurement: Measure the frequency of the pulse signal
Position control: According to the pulse counting results, the position control of the actuator is realized
Direction detection: can detect the direction of the pulse signal
Interrupt function: Support the interrupt function to achieve real-time response
