ABB DSSB-01C

The ABB DSSB-01C module is an important control board in ABB frequency converters, especially in the ACS800 series. It is responsible for the rectifier module control of the inverter, which is the key to the stable operation of the whole inverter system.

Product description
The DSSB-01C module is usually called the rectifier module control board, which realizes the rectification and conversion of the input AC power by controlling the working state of the semiconductor device (such as IGBT), and provides the required DC power for the subsequent link of the inverter.

Product parameters and specifications
Because the DSSB-01C module is a customized component, its specific parameters will vary depending on the inverter model and configuration. In general, its main functions and parameters include:

Features:

Rectifier control: Converts alternating current to direct current.

Overcurrent protection: prevents overcurrent from damaging the device.
Overvoltage protection: prevents overvoltage from damaging the device.
Temperature protection: prevents overheating from damaging the device.
Specifications:
Voltage level: According to the rated voltage of the inverter.
Current capacity: According to the rated current of the inverter.
Size: varies with inverter model.
Interface:
